Laminate veneer restoration using lithium disilicate glass prosthetic restorations

Case by Dr. Yohei Sato, DMD, PhD, Department of Removable Prosthodontics, Tsurumi University School of Dental Medicine, JAPAN and Dr. Keisuke Ihara, CDT, i- Dental Lab, JAPAN.

Fig. 1. The patient visited us with a chief complaint of a desire for improved esthetics of the maxillary right and left lateral incisors.

Fig. 2. A core fabricated from a diagnostic wax model was applied and the necessary clearances were determined.

Fig. 3. Since the teeth are microdonts, the preparation of each abutment was completed by simply exposing a fresh surface to be covered by the laminate veneers.

Fig. 4. A layer of porcelain was applied on the lithium disilicate glass substrate, to make a complete laminate veneer.

Fig. 5. After a trial fitting, the inner surface of the laminate veneer was cleaned with KATANA™ Cleaner. The inner surface was conditioned according to the prosthesis‘ IFU.

Fig. 6. Milling. CLEARFIL™ CERAMIC PRIMER PLUS was applied and dried to silane couple the restoration.

Fig. 7. After a trial fitting, KATANA™ Cleaner was applied to the abutment, and rubbed for more than 10 seconds. Then, it was washed off sufficiently (until the cleaner color had completely disappeared), and dried with compressed air.

Fig. 8. K-ETCHANT Syringe was applied and left for 10 seconds before water-washing and compressed air-drying.

Fig. 9. PANAVIA™ V5 Tooth Primer was applied and left for 20 seconds before compressed-air drying.

Fig. 10. PANAVIA™ Veneer LC Paste was applied to the inner surface of the laminate veneer.

Fig. 11. The laminate veneer was seated and the fit checked. Then, the excess cement was tack-cured (not more than 1 second at any one point) and removed. Finally, the restoration was light-cured and finished.

FINAL SITUATION

Fig. 12. This photo shows the laminate veneer restorations one month after placement. The morphology and color of the right and left lateral incisors have been improved, providing a good balance to the entire anterior dentition.
