Large cavity restoration with resin composite: which materials to choose?

Case by Vasiliki Tsertsidou

What kind of resin composite is recommended for core build-up procedures? While there are specific dual-cure core build-up resin composites available on the market, it is not mandatory to use them. Light curing is advisable to be applied even for materials with dual-cure polymerization. Some conventional resin composites demonstrate more favourable properties for a core build-up compared to specific core build-up resin composites itself.¹ Hence, it is possible to utilize a composite generally used in the dental office, provided it is indicated to and it is not applied deep within the root canal, where proper light curing would be impossible. The critical material properties for core build-ups are high filler load, sufficient flexural modulus and flexural strength.

CLEARFIL MAJESTY™ ES-2 composite series (Kuraray Noritake Dental Inc.) are suitable option for this case. With a filler load weight percentage of 78 and a flexural strength of 118 MPa (according to manufacturer), CLEARFIL MAJESTY™ ES-2 Classic corresponds to core build-up prerequisites*. The following case is illustrating the clinical procedure.

*The indication range of CLEARFIL MAJESTY™ ES-2 composite does not cover core build-up. In the specific case it is used for creating a large Class II filling where all conditions from the IFU, such as curing depth, are met.

Fig. 1. Endodontically treated tooth with a vertical fracture of palatal wall on maxillary right second premolar.

Fig. 2. Buccal view of the tooth.

Fig. 3. Clinical image, directly after removal of fragment.

Fig. 4. Fragment of the maxillary right second premolar.

Fig. 5. Circumferential matrix band for build-up to assist endodontic retreatment.

Fig. 6. Build-up of the missing walls (margin relocation) with CLEARFIL MAJESTY™ ES-2 Classic (A3).

Fig. 7. Temporary filling of the cavity.

Fig. 8. Replacement of the temporary filling material with CLEARFIL MAJESTY™ ES-2 Classic.

Fig. 9. Crown preparation.

Fig. 10. Proximal carious lesion present on the adjacent fist premolar.

Fig. 11. Situation after rubber dam placement and caries removal.

Fig. 12. Cavity restored with CLEARFIL MAJESTY™ ES-2 Classic.

Fig. 13. Prepared crown.

Fig. 14. Crown after sandblasting of the intaglio.

Fig. 15. Mechanically cleaned abutment tooth ready for pre-treatment.

Fig. 16. Intaglio of the crown treated with CLEARFIL™ CERAMIC PRIMER PLUS.

Fig. 17. Etching of the composite surface with phosphoric acid gel.

Fig. 18. Air-drying of PANAVIA™ V5 Tooth Primer on the abutment tooth.

Fig. 19. Crown in place after cementation with PANAVIA™ V5 Paste and excess removal.

A GOOD CHOICE

Dual-cure core build-up resin composites are two-component materials that need to be mixed homogeneously, which obstracts composition from containing high filler load. However, to prevent deformation of the core, a highly filled composite is advisable. This better simulates the flexural modulus of natural tissues compared to materials with low filler load. Consequently, a light-curing material like CLEARFIL MAJESTY™ ES-2 might be a better option. Applied in 2-mm increments in the core area (and not in the root canal), it performs well and provides the desired outcomes. Additionaly, the option of utilising the same material as for any other type of direct restorations is simplifying the stock management and supporting dental practitioners striving for a simplification of clinical procedures.

References

1. Spinhayer L, Bui ATB, Leprince JG, Hardy CMF. Core build-up resin composites: an in-vitro comparative study. Biomater Investig Dent. 2020 Nov 3;7(1):159-166. doi: 10.1080/26415275.2020.1838283. PMID: 33210097; PMCID: PMC7646551.
